Table 17. SAN Volume Controller 2145-8F4 frame assembly (continued)
Assembly index Part number Units Description
- 31P0769 1 80GB SATA HDD
This disk drive, when ordered as a replacement, will be a
supported compatible drive of at least the same capacity as the
one being replaced.
-1 23K4219 1 Top cover
-3 90P1956 1 Riser card, PCI Express
-4 39R9058 2 Heat sink
-5 13M8293 2 Microprocessor, 3.0 GHz
-6 90P5282 1 Heat sink retention module
- 90P5284 1 Chassis
- 23K4209 1 Cage assembly
-7 39Y6958 1 System board
-8 39Y7261 2 Voltage regulator module (VRM), 1U/75A
-9 39Y7169 1 Power supply, 585 watt
- 40K8157 1 Power backplane
- 33F8354 1 Battery, 3.0V
- 40K8160 1 Cable, fan power
- 40K8159 1 Cable, signal, front panel
-10 42C9719 1 Operator information panel
-11 40K8156 1 Fan holder with fan backplanes
-13 40K8139 3 Fan, 40×40×28
-14 40K8140 4 Fan, 40×40×56
- 73P2870 8 Memory, 1 GB ECC DRR2
Table 18. Items not included in the SAN Volume Controller 2145-8F4 frame assembly
Assembly index Part number Units Description
-2 31P0714 1 4-port Fibre Channel host bus adapter
- 23R2770 1 Fibre Channel SFP transceiver
-12 31P0708 1 Service controller
- 23K4218 1 Kit, toolless rail
- 31P1063 1 Power cable assembly (SAN Volume Controller to the 2145
UPS-1U)
- 31P0715 1 Cable retainer
- 39M5699 External Fibre Channel cable, LC–LC, 1.0 m (3.3 ft)
- 39M5700 External Fibre Channel cable, LC–LC, 5.0 m (16.4 ft)
- 39M5701 External Fibre Channel cable, LC–LC, 25.0 m (82 ft)
- 12R9321 External Fibre Channel cable, LC–SC/LC, 1.0 m (3.3 ft)
SAN Volume Controller 2145-8F2 parts
You might need to replace a SAN Volume Controller 2145-8F2 field replaceable unit (FRU).
Chapter 1. Parts listing 17
