DANGER
Multiple power cords. The product might be equipped with multiple power cords. To remove all
hazardous voltages, disconnect all power cords. (L003)
svc00322
1
2
or
1
2
svc00735
or
1
3
4
2
svc00734
Perform the following steps to replace the SAN Volume Controller high-speed SAS adapter assembly,
after removing an adapter that was already configured:
1. Read the safety information to which “Preparing to remove and replace parts” on page 26 refers.
2. Attach the high-speed SAS cable to the connector on the bottom of the high-speed SAS adapter, as
described in “Replacing the SAN Volume Controller 2145-CG8 or 2145-CF8 high-speed SAS cable” on
page 204.
Attach the cable so that the end with the label is to the front of the node and the end without the
label attaches to the adapter.
3. Insert the adapter into the riser card, then insert the assembly into the slot 2 connector on the system
board.
As you start inserting the adapter, align the edge connector on the low-profile adapter with the
connector on the riser-card assembly. Make sure that the adapter snaps into the riser-card securely.
Then press the riser-card edge connector 2 firmly into the system-board slot 2 connector 1,as
shown in Figure 196 on page 200.
When viewed from the back of the node, the slot 1 connector is on the left and contains the Fibre
Channel adapter assembly. The slot 2 connector is on the right when viewed from the back of the
node.
Chapter 2. Removing and replacing parts 199
|
|
|
|
|
||
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
