6: ALLOCATION NUMBERS
6-16 OPENNET CONTROLLER USER’S MANUAL
Special Data Registers for Modem Mode
D8172 INTERBUS (Node 30) ID Code When initialized 24-6
D8173 INTERBUS (Node 30) Device Level When initialized 24-6
D8174 INTERBUS (Node 31) Logical Device No. When initialized 24-6
D8175 INTERBUS (Node 31) Length Code When initialized 24-6
D8176 INTERBUS (Node 31) ID Code When initialized 24-6
D8177 INTERBUS (Node 31) Device Level When initialized 24-6
D8178 INTERBUS Master System Error Information When initialized 24-10
D8179 INTERBUS Master Status Transition Number When accessed 24-10
D8180 INTERBUS Master Acknowledge Code When accessed 24-10
D8181 INTERBUS Master Additional Error Information When accessed 24-10
D8182 INTERBUS Master Error Code When accessed 24-10
D8183 INTERBUS Master Error Location When accessed 24-10
D8184-D8199 — Reserved ———
Allocation
Number
Description Updated See Page
D8200 Port 1 RS232C Port Communication Mode Selection Every scan 23-3
D8201 Port 1 Modem Initialization String Selection Every scan 23-3
D8202 — Reserved ———
D8203 Port 1 On-line Mode Protocol Selection When sending/receiving data 23-3
D8204 Port 1 Control Signal Status Every scan 17-27
D8205 Port 1 DSR Input Control Signal Option When sending/receiving data 17-28
D8206 Port 1 DTR Output Control Signal Option When sending/receiving data 17-29
D8207 Port 1 RTS Output Control Signal Option When sending/receiving data 17-29
D8208 — Reserved ———
D8209 Port 1 Retry Cycles At retry 23-3
D8210 Port 1 Retry Interval Every scan during retry 23-3
D8211 Port 1 Modem Mode Status At status transition 23-3
D8212-D8214 — Reserved ———
D8215-D8229 Port 1 AT Command Result Code When returning result code 23-3
D8230-D8244 Port 1 AT Command String When sending AT command 23-3
D8245-D8269 Port 1 Initialization String When sending init. string 23-3
D8270-D8299 Port 1 Telephone Number When dialing 23-3
D8300 Port 2 RS232C Port Communication Mode Selection Every scan 23-3
D8301 Port 2 Modem Initialization String Selection Every scan 23-3
D8302 — Reserved ———
D8303 Port 2 On-line Mode Protocol Selection When sending/receiving data 23-3
D8304 Port 2 Control Signal Status Every scan 17-27
D8305 Port 2 DSR Input Control Signal Option When sending/receiving data 17-28
D8306 Port 2 DTR Output Control Signal Option When sending/receiving data 17-29
D8307 Port 2 RTS Output Control Signal Option When sending/receiving data 17-29
D8308 — Reserved ———
D8309 Port 2 Retry Cycles At retry 23-3
Allocation
Number
Description Updated See Page
