6 - USE AND OPERATION Master 80 UP HyperFlexible
6 - Pag. 10 / 10
6.4 LIGHT INDICATOR - SIGNAL DESCRIPTION
BLINKING ORANGE LIGHT; indicates that, with the
bar feeder in automatic mode, the magazine is in
manual mode.
BLINKING ORANGE LIGHT; indicates that the
magazine is open. (OPTIONAL)
FIXED GREEN LIGHT; indicates that the bar feeder is
in the automatic mode.
FIXED RED LIGHT; indicates that the bar feeder is
not operating, or that it is in the manual
mode. (OPTIONAL)
BLINKING BLUE LIGHT; the bar feeder is carrying
out the bar change.
FIXED BLUE LIGHT; indicates that the PLC battery is
exhausted. (OPTIONAL)
