4 - HANDLING AND INSTALLATION Master 80 UP HyperFlexible
4 - Pag. 10 / 10
• Roughly adjust the height of the working axis
and the alignment with the lathe by turning the
screws of the support feet.
4.4.4 Front nose - Installation
• Install the front nose (A) in the
bush holder device.
• Install the oil recovery tank (B).
• Connect the lubrication pipe (C)
to the front nose.
• Connect the drain pipe (D) to the
tank
