11 - COLLETS Master 80 UP HyperFlexible
11 - Pag. 40 / 40
11.29 RINGS FOR COLLETS 078-225
11.30 RINGS FOR COLLETS - Table
A Revolving tip
B Collet
C Ring
øA (mm) øB (mm) øD (mm) øF
Ring p/n.
8 14 16 22540008(*)
12 18 20 22540004(*)
12 25 25 078800220(*)
17 24 30
M17x1
22540026
17 30 35 078800200
25 30 30
M25x1.5
078800220
25 35 40 22540009
25 45 51 078800230
(*) Only for collets 316 (TAL)
