4 - HANDLING AND INSTALLATION Master 80 UP HyperFlexible
EN
4 - Pag. 17 / 17
4.5 LUBRICATION OIL - FILLING
WARNING - CAUTION:
wear personal protections according to
the regulations in force.
• Remove cover (A).
• Pour the oil directly into the tank and check the
level through the relevant indicator (B).
Oil features: Class (C) - CKB 150, quantity 80 l.
4.6 ELECTRICAL CONNECTION
DANGER - WARNING:
this type of operation should only be entrusted to skilled personnel with precise
technical competence and specific abilities to comply with the applicable
standards and regulations in force. The feeder must be electrically connected to
the lathe, which in turn, must be connected to the electrical installation in
compliance with the applicable regulations in force.
The bar feeder is normally equipped with a multiple plug to be inserted into the special lathe
socket; refer to the "Wiring diagram" if necessary.
