5 - ADJUSTMENT AND SETUP Master 80 UP HyperFlexible
5 - Pag. 2 / 2
5.1 ADJUSTMENT AND SETUP - FOREWORD
DANGER - WARNING:
do not perform any adjustment when the bar feeder is running unless expressly
requested in the manual.
This bar feeder requires, besides the ordinary adjustments necessary during its life, also
adjustments depending on the bar dimensions and the magazine type.
5.2 GENERAL ADJUSTMENTS - FOREWORD
All the necessary adjustments for correct bar feeder operation are included. They may become
necessary for maintenance, troubleshooting or component replacement.
5.2.1 Feeding chain - Adjustment
• Remove the screw (E), lower the
rear lever and move the bar
feeder body backwards.
WARNING - CAUTION:
before performing this
operation, open the upper
guard and power the lathe
off.
E
A01PF_MUM_05_03_00
