5 - ADJUSTMENT AND SETUP Master 80 UP HyperFlexible
EN
5 - Pag. 5 / 5
5.3 BAR FEEDER SETUP
If the diameter of the bars to be machined changes, it may be necessary to perform
adjustments on the machine.
Refer to the "Guide channel, bar pusher, bar and pipe diameter" table in section 2.
5.3.1 Guide channels, half bushes, bar pusher and collet - Replacement
• Press to start the bar feeder.
• press
and to select the
semiautomatic function.
• Press
several times until the upper guide
channels open; "GUIDE CHANNEL FULL
OPENING" should appear on the display.
• Press
and open the upper guard.
