IEMCA Master 80 UP HyperFlexible - Recommended Spare Parts; Disposal of the Bar Feeder or Parts of It

9 - PART REPLACEMENT Master 80 UP HyperFlexible
EN
9 - Pag. 5 / 5
9.5 RECOMMENDED SPARE PARTS
The parts subject to wear or easily breakable parts are listed below (for a period of two years,
normal use of the bar feeder).
Model Code Name Features Notes Qty
MASTER 80 UP
HyperFlex
24220108 Feeding chain 1/2”x5/16” Vers.33 1
24220109 Feeding chain 1/2”x5/16” Vers.38 1
24220121 Feeding chain 1/2”x5/16” Vers.43 1
24290606 Connecting link 1/2”x5/16” 1
32210004 Sensor 3RG4012-0AG07 1
32210013 Sensor 3RG4012-0AG33 1
32210017 Sensor 3RG4012-0AG00 1
32210019 Sensor 3RG4012-0AG33-Z 1
Bar pusher
Specify diameter
and length
1
Revolving tip Specify diameter 1
Collet
Specify internal and
external diameter
1
To order the parts refer to the Spare Parts Catalogue.
9.6 DISPOSAL OF THE BAR FEEDER OR PARTS OF IT
INFORMATION:
this operation must be carried out by specialized operators, in accordance with
the laws in force on safety at work. Do not throw non-biodegradable products,
lubricating oils and non-ferrous components (rubber, PVC, resins, etc.) in the
environment. Dispose of the materials in compliance with the laws in force.
