6 - USE AND OPERATION Master 80 UP HyperFlexible
6 - Pag. 12 / 12
SOLID BARS
Make sure that there is not too much rag on
the front end, which might hinder from
entering the lathe collet.
The bar rear end must be chamfered as
indicated in the figure.
If bars with front remnant ejection have to be
machined, we advise to chamfer the bar rear end as
shown in the figure.
When machining bars having a diameter equal to or
only slightly smaller than the bar pusher diameter,
it is necessary to turn the bar rear ends; diameter
"D" should be suitable for the collet installed in the
bar pusher.
PIPES
If pipes are to be machined, the rear end of
the pipe must be chamfered as shown in the
figure.
