11 - COLLETS Master 80 UP HyperFlexible
11 - Pag. 14 / 14
Code structure
CH*: double-ended fork wrench DIN3110
A Collets for pipe (type AS) øF M7x0.75 - M8x1
B Collets for pipe (type BOSS) øF M10x1
C Collets for pipe (type T560) øF M17x1 - M25x1
D Collets for pipe (type T560) øF M25x1.5
E Bar diameter
F Example:
5 mm = 060
10 mm = 100
12.5 mm = 125
G Category
