EN
5 - ADJUSTMENT AND SETUP SMART320
5 - Pag. 10 / 20
Adjust the front half-bushes as follows:
• Press the manual control on the solenoid valve
for bush opening/closing to close the half-
bushes.
• Now turn the knob either way to reach the
diameter of the bar: make sure the bar can
slide freely.
• Replace the half-bushes in case of wear or
when changing the machining range:
loosen the screws (B) and replace the
bushes (C).
• Remove the internal sleeve.
• If necessary, remove the lathe spindle liner and
install another one suitable for the diameter of
the guide channel.
