SYS Mode Displays
Top-Level Displays
Top-Level functions are accessed by entering SYS Mode and turning
the Large knob. These functions are: Navigation Info, System Info,
Position Sensors, and Miscellaneous Sensors. Pressing ENT places
the system in the sub-state described on the top line. For example,
pressing ENT when the top-level page reading “NAVIGATION
INFO” (top line) and “PRESS ENT” (bottom line) is displayed, places
the system in the Navigation Info sub-state, and the knobs are then
used to access displays pertaining to navigation data and settings.
Navigation Information
Pressing ENT when the screen below is displayed provides access to
Airspace Setup, Autonav Time, NAV Mode Display Programming,
Mag Variation (Magnetic Variation), the Flight Timer Trigger, and
Direct-To Entry option.
NAVIGATION INFO
PRESS ENT
SYS
System Information
Pressing ENT when the screen below is displayed provides access to
Time and Date settings, Fuel Measure Units, Barometric Measure
Units, Software Version information, Display Testing, and Owner
Information.
SYSTEM INFO
PRESS ENT
SYS
163
Operations SYS Mode Displays
