Displaying SUA (Special Use Airspace) Information
The following procedure is used to display information on a SUA after
a SUA message has been generated.
Action Explanation
1. Display the SUA
message.
In MSG mode, display the message
alerting you to an SUA.
Within 10NM of
Seattle
Class B
2. Press INFO to display information of
the SUA. The top line of the display
shows the ceiling. The middle line
shows the floor, and the bottom line
shows the bearing, approximate relative
bearing, and the distance to the nearest
edge of the SUA. In this example, the
ceiling is 10,000 ft, the floor is the
surface (ground), the bearing is 154
o
,
the SUA is straight ahead, and the
distance is 8.9 nm.
CEIL: 10000’MSL
FLOOR:½ GROUND
BRG 154° 8.9NM
3. Press INFO again to exit the
Information function.
Within 10 NM Of
SEATTLE
CLASS B
58
Message Displays Operations
INFO
INFO
