Displaying Miscellaneous Sensor Information
The following procedure is used to display miscellaneous sensor
information.
Action Explanation
1. In SYS mode, turn the Large knob to
display the Misc Sensors page.
MISC SENSORS
PRESS ENT
SYS
2. Pressing ENT activates the
Miscellaneous Sensor sub-state
functions. Turn the Large knob to
display the Air Data Sensor top page,
the Fuel Data Sensor top page, or the
altitude encoder page.
AIR DATA INFO
TruAirSp 385kts
IndAirSp 304kts
SYS
3. If the diamond character is displayed
on the lower right hand corner of the
display page, rotate the Small knob to
view sub-pages of the current page.
TrueAir 24°C
OutAir 14°C
Turn 3°/Sec L
SYS
220
Miscellaneous Sensor Sub-State Operations
SYS
ENT
