If the Fuel/Air Data Sensor is part of your system, the following
default sub-pages are also available.
FUEL TO 25USG
FUEL AT 75 USG
BURN 14.3USG/HR
INDAIRSP 153KTS
TRUAIRSP 147KTS
GROUNDSP 132KTS
WIND DIR 131°MAG
WIND DIR 122°TRU
WIND SPD 30KTS
Eight Character Nav Items
Each navigation item explained below uses half of a display line. All of
these items are available when you customize your navigation displays.
The BRG (Bearing) Nav item, depicted below, shows the magnetic
bearing to the To waypoint from your present location. In this example,
the bearing is 253
o
.
BRG 253
The distance Nav items, depicted below, show the distance in nautical
miles to the To waypoint from your present location. In this example,
the distance is 116 nautical miles.
116NM
The TRK (Track) Nav item, depicted below, shows the current
magnetic ground track. In this example, the track is 213
o
.
TRK 213
70
NAV Displays Operations
