Loran Sensor Sub-State
The Position Sensor sub-state is used to display and modify position
sensor settings. If Loran sensor(s) are installed, this information
includes: TDs (Time Differences), OSC (Reference Oscillator)
frequency and temperature, GRI’s, and Triads.
If GPS sensor(s) are installed, this information includes: the number of
healthy satellites, the number of visible satellites, present altitude,
track, ground speed, identifiers of the satellites used, the UTC
(Coordinated Universal Time), satellite status, satellite elevation,
SNR (Signal to Noise Ratio), and Azimuth.
Displaying Position Sensor Information
The following procedure is used to display position sensor data.
1.
In SYS mode, turn the Large knob to
display the Position Sensors page.
POSITION SENSORS
PRESS ENT
SYS
2.
Pressing ENT activates the Position
Sensor sub-state functions. Turn the
Large knob to display the desired Loran
GRI page.
LORAN1 GRI 9940
US WEST COAST
GRADE 93 AUTO ·
SYS
3.
Turn the Small knob to display station
data.
LORAN1 GRI 9940
W 12660.92 TRACK
93 22/78
SYS
214
Loran Sensor Sub-State Operations
SYS
