System Info Sub-State Displays (continued)
GPS Firmware Version
The display below shows the internal GPS Firmware (FW). The
version shown is 016.
GPS:INT’L VERS
FW VERS 016
SYS
Loran Software Version
The display below shows the Loran 1 software version is 1.00, and the
antenna is top mounted.
LORAN1
SW VERS 1.00
ANTENNA MT: TOP
SYS
AirData Computer Version
This display shows the version of the AirData Computer.
AIRDATA COMPUTER
SW VERS 1.00.02
FW VERS 90.01.01
SYS
Display Test
The screen below is used to test the NMC display.
TO TEST DISPLAY
PRESS ENT
·
SYS
Owner Name
The display below shows the owner’s name is Clark Kent. The NMC
allows you to enter your name, address, phone number, and aircraft
number into the NMC memory. This information is protected by an
owner entered password.
169
Operations SYS Mode Displays
