System Info Sub-State Displays (continued)
Baro Measure Units
The screen below is used to choose the measurement units used in
barometric pressure adjustment displays in inches or millibars.
BARO MEASURE
"
INCHES
SYS
NMC Software Version
The display below shows the NMC software version and part number.
The software version information may be important when
servicing/troubleshooting the NMC. In this example, the NMC
software version is 6.30 and part number is 139-0197-063. Turn the
Small knob to display data base, Gateway/Keypad, GPS Sensor, Loran
Sensor, and AirData Computer information.
APOLLO NMC
139-0197-063
·
SYS
Data card Version
The display below shows the installed data card is North America,
version 1.10. The expiration date for this version is March 31, 1999.
NORTH AMERICA DB
DATE: 03/31/99
VERSION: 1.11
SYS
Gateway/Keypad Version
GATEWAY/KEYPAD
SW VERS 1.00
FW VERS 016
SYS
168
SYS Mode Displays Operations
