Position Sensors
Pressing ENT when the screen below is displayed provides access to
Loran/GPS sensor settings and data.
POSITION SENSORS
PRESS ENT
SYS
Miscellaneous Sensors
Pressing ENT when the screen below is displayed provides access to
Air Data Info, Fuel Info data, and pressure altitude.
MISC SENSORS
PRESS ENT
SYS
Navigation Info Sub-State Displays
Airspace Setup
The navigation information sub-state screens are used to display and
edit various navigation settings. The display below is used to turn
Airspace Alerts ON/OFF.
AIRSPACE SETUP
ALERTS: ON ·
SYS
Airspace Buffers
Airspace Alert provides alert messages based on distance, altitude, and
time. The page below is used to set the airspace buffers. In this
example, you will be alerted when the aircraft is 2 nm from a SUA
(Special Use Airspace), within 500 feet of the floor/ceiling of a SUA,
and are 10 minutes from penetrating a SUA. These settings are the
default (factory) settings.
164
SYS Mode Displays Operations
