AIRSPACE BUFFERS
DIST ALT TIME
2NM 500’10MIN
SYS
Airspace Select
The display below is used to select the type of SUAs that will generate
alert messages. A similar page is displayed for each type of SUA. SUA
alert options include: Class B and C airspaces, MOAs, Training Areas,
Unknown SUAs, Alert Areas, Caution Areas, Danger Areas,
Restricted Areas, Prohibited Areas, and Warning Areas. When Class B
OUTER or Class C OUTER is chosen, only one alert message is
generated when multiple Class B or Class C airspaces overlap; i.e. the
system considers the overlapping airspaces to be a single SUA.
AIRSPACE SELECT
CLASSB :OFF
B OUTER : ON
SYS
Autonav Time
The display below is used to set the Autonav Scroll time. In this
example, Autonav Scroll will display each Nav information page
sequentially at 4 second intervals. When viewing the NAV mode home
page, press ENT to activate Autonav Scroll. Press ENT again to stop
scrolling.
AUTONAV TIME:
4 SECONDS/PAGE
SYS
165
Operations SYS Mode Displays
