Navigation Info Sub-State Displays (continued)
Nav Mode Display Programming
The display below is used to customize Nav pages. This feature allows
you to choose the specific navigation items displayed in NAV mode.
NAV MODE DISPLAY
PROGRAMMABLE AND
AUTONAV PAGES
SYS
Magnetic Variation
The display below shows the magnetic variation is set on automatic,
and is currently 09
o
W (West). Magnetic variation information is
drawn from the data card. The magnetic variation may also be entered
manually, and must be entered manually if a valid data card is not
inserted.
MAG VARIATION
AUTO 09°W
SEL TO EDIT
SYS
Changing Oceanic Activation Altitude
The display below shows the Oceanic Activation Altitude currently set
to 16000 feet. Activation altitude is adjustable in 100 foot increments
over the range of 0 to 18000 feet.
OCEANIC ALTITUDE
16000 FT
SEL TO EDIT
SYS
Flight Timer Trigger
The display below is used to adjust the Flight Timer Trigger speed.
Flight Trigger choices are: OFF, At Power On, and selectable for
speeds from 10 to 500 knots. In this example, the Flight Timer is
activated when the ground speed exceeds 30 knots.
FLIGHT TIMER
TRIGGER
AT 30 KTS
SYS
166
SYS Mode Displays Operations
