CDI Scaling
The CDI Scaling option allows you to choose between Automatic and
Manual Scaling. If Auto CDI Scaling is on, CDI scaling will be 5.00
nm full scale per side. The manual CDI scaling may be set to 0.3, 1.0,
or 5.0 nm full scale per side. In an active approach operation, CDI
scaling is locked in automatic and will change according to your
distance to the destination waypoint for the approach operation flight
phase.
The following procedure is used to edit the Auto CDI Scaling Option.
Action Explanation
1. In SYS mode, turn the Large knob to
display the Navigation Info page.
Navigation Info
Press ENT
SYS
2. Pressing ENT activates the Navigation
Info Sub-State functions. Turn the
Large knob to display the CDI Scaling
Option page.
CDI SCALING
AUTOMATIC
ªªªªª 5.00nm
SYS
199
Operations Navigation Information Sub-State
SYS
ENT
