Mag Heading 347°
Desired Hdg 321°
Turn 2°/sec L
SYS
The last Air Data Sensor display shows:
·
True Wind Direction
·
Magnetic Wind Direction
·
Wind Speed
Wind Dir 110°tru
Wind Dir 110°mag
Wind Spd 27kts
SYS
Fuel Data Sensor Information
If the system does not include an F/ADS, the next display is the only
page shown for the Fuel Data Sensor Information.
Fuel Info
No Data
Available
SYS
If the Fuel Data Sensor information is available, the next screens are
available for information on the Fuel Data Sensor.
The first Fuel Data Sensor display shows:
·
Estimated Fuel Endurance, based on the current amount of fuel
in the regular (non-reserve) tanks and the current burn rates
·
Nautical Miles per Fuel Unit
·
Remaining fuel, not including reserve tanks
Endurance 01:34
nm per usg 12.4
Remain 142usg
SYS
176
SYS Mode Displays Operations
