The following legs replace the BKE airport in the flight plan and
describe the approach sequence.
D272Y TO D297Y
3* O18° 10.8NM
IAF ARC
D297Y TO D297O
4* 118° 10.0NM
ARC APPR
D297O TO CF12
5* 119° 5.0NM
APPR APPR
CF12 TO FF12
6* 120° 6.0NM
APPR FAF
FF12 TO MA12
7* 120° 3.2NM
FAF MAP
MA12 TO BKE
8* 120° 0.8NM
MAP MAHP
Notice that these waypoints are all depicted on the example Jeppesen
Approach plate; however, only BKE is depicted as such on the NOS
plate (shown on the following page).
230
Approach Procedures Operations
