3. Use the Arc Assist page as the primary guidance for flying the DME
Arc and manually activate the inbound leg. Press FPL to reach
Flight plan. Turn the Large knob if necessary to reach the active
flight plan. Turn the Small knob to display the “D185O to CF005”
display.
D1850 TO CF005
4* 009° 3.0NM
ARC APPR
4. Press ENT to start manual leg selection. Press ENT to accept the
displayed leg.
D1850 TO CF005
PRESS ENT
TO ACTIVATE LEG
5. Turn the Large knob to the Arc Assist page.
Point B (On the arc between MUGGZ and D1850.
1. Make sure that you are viewing the “Right” Arc Assist page. Turn
the Small knob, if necessary.
RGHT ARC DTK 270
REF: LTJ VOR
RAD 180° 16.1NM
2. Use the Arc Assist page and your aircraft heading display to
navigate to the selected inbound leg. The Desired Track (DTK) is
yourtangenttothe arc onyourpresentradial. For therightturnarc in
this example, there are no other Arc waypoints to identify. If there
were more waypoints, the Arc Assist page will continuously show
the radial and distance from the Arc Reference making them easy to
identify from your approach chart.
296
