Top-Level Nav Displays (continued)
The Parallel Course Offset display is depicted below. In this example, the
offset is 1.4 nm to the right, and in Standby status. The offset is not in effect
until the “In Use” status is entered. For procedural information, see
Operations, Parallel Course Offset. Maximum Parallel Course Offset is
20.0 nm. Parallel Course Offset is disabled during an active approach
operation.
Parallel Course Offset Display
PARALLEL COURSE
OFFSET: STANDBY
RIGHT 1.4NM ·
The Position Display shows the position sensor in use, the
Latitude/Longitude position, and the EPE (Estimated Position Error).
GPS Sensors do not display an EPE. In this example, the In Use position
sensor is Loran 1, and the present Lat/Lon is 45°27.45’N, 122° 51.32’ W.
Position is displayed in degrees, minutes, and hundredths of a minute.
Seconds of Lat/Lon are not used. The EPE is 0.7 nm. If position has not
been calculated, the top line of the display reads, “Last Valid Position.”
Position Display
LORAN1 IN USE(A)
45°27.45N EPE
122°51.32W O.7
Countdown Timer Display
The Countdown Timer display is depicted below. In this example, the
timer is set for 3 minutes. For procedural information, see Operations,
Setting/Starting the Countdown Timer.
COUNTDOWN TIMER
00:03:00
67
Operations NAV Displays
