The Density Altitude Nav item is shown next. Requires F/ADS or
ARINC 429 Air/Data sensor and XYZ heading input.
Dens Alt 2900ft
The Mach Number Nav item is depicted below. Requires F/ADS.
Mach .800
The Turn Rate Nav item, which displays the current rate of turn of the
plane, is shown next. It is in degrees of turn per second left (L) or right
(R). Requires F/ADS.
Turn 005°/sec L
The Outside Air Temperature Nav item, which does not take wind
factors into account, is depicted below. In this example, the Outside
Air Temperature is -20° centigrade. Requires F/ADS.
OutAir° -20°C
The True Air Temperature Nav item, which factors in wind speed
relative to a 0 knot ground speed is depicted next. In this example, the
True Air Temperature is 10° centigrade. Requires F/ADS.
TrueAir° 10°C
The True Air Speed Nav item, which displays the air speed of the plane
after correction for altitude and temperature factors, is displayed next.
Requires F/ADS or ARINC 429 Air/Data sensor and XYZ heading input.
TruAirSp 153kts
The Indicated Air Speed Nav item, which displays the air speed of the
plane without correction for altitude and temperature factors, is
displayed next. Requires F/ADS.
IndAirSp 234kts
The Burn Rate Nav item, which displays the amount of fuel usage per
hour, is shown next. The units of fuel (liters, gallons, pounds, or kilos)
may be customized in System Mode. Requires F/ADS.
Burn 12,8usg/hr
76
NAV Displays Operations
