5.3 Menu Configuration and content
■
VIDEO I/O
Sets the assignment of video signals for input/output connector of the camera.
Menu Item
Initial
setting
Setting value Description, Remarks
SDI OUT1 SEL
VF
RET-1, RET-2, RET-3,
RET-4, HD Q-TV1, HD
Q-TV2, VF, MON, RET-1
SEL, RET-2 SEL
Sets the signals outputted from the SDI OUT1 connector.
When they are set to RET-1 SEL and RET-2 SEL, they are linked to RET-1/RET-
2 selector switch on the back.
SDI OUT2 SEL
VF
RET-1, RET-2, RET-3,
RET-4, HD Q-TV1, HD
Q-TV2, VF, MON, RET-1
SEL, RET-2 SEL
Sets the signals outputted from the SDI OUT2 connector.
When they are set to RET-1 SEL and RET-2 SEL, they are linked to RET-1/RET-
2 selector switch on the back.
SDI OUT3 SEL
VF
RET-1, RET-2, RET-3,
RET-4, HD Q-TV1, HD
Q-TV2, VF, MON, RET-1
SEL, RET-2 SEL
Sets the signals outputted from the SDI OUT3 connector.
When they are set to RET-1 SEL and RET-2 SEL, they are linked to RET-1/RET-
2 selector switch on the back.
SDI I/O4 SEL
VF
RET-1, RET-2, RET-3,
RET-4, HD Q-TV1, HD
Q-TV2, VF, MON, RET-
1 SEL, RET-2 SEL, HD
TRUNK
Sets the signals outputted from the SDI OUT4 connector.
When they are set to RET-1 SEL and RET-2 SEL, they are linked to RET-1/RET-
2 selector switch on the back.
Only SDI I/O4 can be set to the HD TRUNK input.
BARS MODE( E)
Setting
value
FULL, MULTI
)8// 'LVSOD\VWKH%$56VLJQDOVXVHGKLVWRULFDOO\
08/7,'LVSOD\VWKHPXOWLIRUPDW%$56VLJQDOV
BARS( E)
OFF ON, OFF 6ZLWFKHVEHWZHHQ212))RIWKHFRORU%$56VLJQDOV
Caution:
&+$5 &KDUDFWHUJHQHUDWRUWHVWVLJQDOV
021 0RQLWRUYLGHRVLJQDORXWSXWIRU&&8
