Ikegami CCU-430 - Operating from OCP-300

133
UHK-430/CCU-430 1710 VER2 (E)
6.1 Basic Operation of Menu Screen
CCU SETTINGS and ADJUSTMENT
6
■
Operating from OCP-300
1 Press the "SETUP" switch of OCP-300 to display the
SETUP items on the OCP LCD screen.
PM screen
2 Press and hold the MENU switch to display the menu
screen on the PM screen.
<RXFDQSHUIRUPYDULRXVVHWWLQJVRQWKHVXEPHQXWKDWLV
displayed from the main menu on the PM screen.
3 Make sure that the main menu screen is displayed on
the PM screen.
4 Turn the Select knob or Next knob to position the flashing cursor on the setting item, and press the Enter switch
on the LCD.
The submenu appears, on which you can perform various settings.
Note:
Depending on the functions of the setting items, some items change the setting when the knob is turned; others change the setting
when the Enter switch on the LCD is pressed.
5 Exiting the nemu
Exit the menu screen in the any of the following methods.
- Select "
" on the CCU main menu and press the Enter switch.
- Press the QUIT switch on the LCD.
SETUP switch
MENU switch
OCP-300
Enter switch
Select knob Next knob
Quit switch
