6.1 Basic Operation of Menu Screen
The following explains the method to display the main menu on the PM screen.
1 Press and hold the MENU switch of MCP.
Display the main menu on the PM screen.
2 Turn the RE knob under "Select" and "Next"
of MCP to change the item. Then press the
Enter switch in the MCP LCD screen and
confirm.
Display the sub menu selected and perform
various settings
3 Turn the RE knob under "Select" and "Next"
of MCP on the sub menu screen to select the
item. Then press the Enter switch in the MCP
LCD screen. Move to the setting screen. (The
sub menu may be continued for some items.)
4 On the setting screen, select the item and
confirm (press the Enter switch). Then, turn
the RE knob of the MCP screen to select the
setting value.
CAUTION:
Depending on the functions of the setting items, some items change the setting when the knob is turned; others change the setting
ZKHQWKH&$//EXWWRQLVSUHVVHG
Note:
- To return to the main menu, select " DQGSUHVVWKH&$//EXWWRQ
7KHÀDVKLQJLWHPRQWKHVXEPHQXLQGLFDWHVWKHFXUUHQWO\IRFXVHGLWHP7KLVÀDVKLQJVWDWXVLVFDOOHGWKHÀDVKLQJFXUVRUKHUHDIWHU
(displayed in gray in the display example).
(DFKWLPHWKH&$//EXWWRQLVSUHVVHGWKHÀDVKLQJFXUVRUVZLWFKHVWRVHWWLQJLWHP!PRGHVHOHFWLRQ!VHWWLQJLWHP!PRGH
selection and so on.
5 Exiting the nemu.
Exit the main menu screen and sub menu screen displayed on the PM screen by following one of the methods
described below.
- Select "
RQWKH&&8PDLQPHQXDQGSUHVVWKH&$//EXWWRQ

