Ikegami CCU-430 - Diagnosis

137
UHK-430/CCU-430 1710 VER2 (E)
6.2 CCU Menu Configuration and Contents
CCU SETTINGS and ADJUSTMENT
6
■
DIAGNOSIS
Monitors various modules and elements and displays the results.
Setting Item Initial setting Setting value Description, Remarks
TEMPERATUR
Displays the temperature information (Celsius) of the device.
―
HD_VP
―
FPGA2
xx.x
―
FPGA3
xx.x
―
ASIC L
xx.x
―
ASIC R
xx.x
―
TRX_VP
―
FPGA1
xx.x
―
FPGA2
xx.x
―
FPGA3
xx.x
―
ASIC L
xx.x
―
ASIC R
xx.x
―
OPT T/R
xx.x
―
RET_PRC
―
FPGA1
xx.x
―
FPGA2
xx.x
―
PLS/AUX
xx.x
―
MPU
xx.x
―
POWER_IF
xx.x
―
12G_OUT
FPGA
xx.x
OPT RX CONDITION
'LVSOD\VWKH/26)/$*VWDWXVRIRSWLFDOWUDQVFHLYHU
―
Rx1 LOS FLAG
OK OK/LOS
―
Rx2 LOS FLAG
OK OK/LOS
―
Rx3 LOS FLAG
OK OK/LOS
Rx4 LOS FLAG
OK OK/LOS
TRX_VP CRC
Displays the results obtained by CRC monitoring of TRX_VP module.
―
GROUP 1 R/G/B
OK/ OK/ OK OK/ERROR
―
GROUP 2 R/G/B
OK/ OK/ OK OK/ERROR
―
GROUP 3 R/G/B
OK/ OK/ OK OK/ERROR
―
GROUP 4 R/G/B
OK/ OK/ OK OK/ERROR
―
GROUP 5 R/G/B
OK/ OK/ OK OK/ERROR
―
GROUP 6 R/G/B
OK/ OK/ OK OK/ERROR
―
GROUP 7 R/G/B
OK/ OK/ OK OK/ERROR
―
GROUP 8 R/G/B
OK/ OK/ OK OK/ERROR
―
CAM_MON/VF
OK OK/ERROR
―
HD QTV
OK OK/ERROR
―
RET VIDEO-A
OK OK/ERROR
RET VIDEO-B
OK OK/ERROR
RET_PRC CRC
Displays the results obtained by CRC monitoring of RET_PRC
module.
―
RET-1
OK OK/ERROR
―
RET-2
OK OK/ERROR
―
RET-3
OK OK/ERROR
―
RET-4
OK OK/ERROR
―
QTV-1
OK OK/ERROR
―
QTV-2
OK OK/ERROR
―
4K EDGE
OK OK/ERROR
―
D/C_VF
OK OK/ERROR
HD TRK
OK OK/ERROR
