SPECIFICATIONS
9
219
UHK-430/CCU-430 1710 VER2 (E)
9.2 External Dimensions Diagram
CCU
■
Front Side View
31.75
±0.5
2- 5.22- 7
50.4
±1
132.6
±3
57.2
±1
37.7
±0.5
465 ±1.5 482.6 ±5
4- 7x10
57.2
CAM:400V T5A
POWER
CCU
CAM
TEMP
FAN
ALARM
COMM
SDI
APC
GENLOCK
CCU STATUS
SHORT
OPEN
NORMAL
CABLE STATUS
OPT RX LEVEL
CAM
CCU
TALLY
ID
INTERCOM
PHONE
INIT/PM
CALL
COM
PRV
MIC
ON
OFF
PTT
MENU
USB
OPE
OFF
