UHK-430/CCU-430 1710 VER2 (E)
5.3 Menu Configuration and content
■
INTERCOM/AUDIO
Performs various settings according to the operation of intercom and audio.
[MIC GAIN CONTROL]
Menu Item
Initial
setting
Setting value Description, Remarks
MIC GAIN CONTROL
―
MIC1 SETUP
―
MIC1 SETUP
SELECT
MIC MIC / LINE
Sets the microphone mode.
The power is supplied according to the MIC-1 POWER switch on the back side of
the camera during the MIC setting.
The power supply is stopped regardless of the MIC-1 POWER switch on the back
side of the camera during the LINE setting.
―
MIC1 STEP
-40dB
+4dB, 0dB, -10dB,-20dB,
-30dB, -40dB,
G%G%
The MIC1 gain is changed step by step.
MIC1 FINE
0-100
t
o100
Fine adjustment of the MIC1 gain. The gain decreases about -10 dB with -100,
and increases about +10 dB with +100.
MIC2 SETUP
―
MIC2 SETUP
SELECT
MIC MIC / LINE
Sets the microphone mode.
The power is supplied according to the MIC-2 POWER switch on the back side of
the camera during the MIC setting.
The power supply is stopped regardless of the MIC-2 POWER switch on the back
side of the camera during the LINE setting.
―
MIC2 STEP
-40dB
+4dB, 0dB, -10dB,-20dB,
-30dB, -40dB,
G%G%
The MIC2 gain is changed stepwise.
MIC2 FINE
0-100
t
o100
Fine adjustment of the MIC2 gain. The gain decreases about -10 dB with -100,
and increases about +10 dB with +100.
