Helpful Technical Information
7
7.1 4K Format
155
UHK-430/CCU-430 1710 VER2 (E)
■
HD Format
Format SDI Signal Standard
1920x1080 interlace 60/M 1080i59.94 1.485/M Gbps 422 274M/292M
1920x1080 progressive(sF) 24/M 1080PsF23.98 1.485/M Gbps 422 274M/292M
1920x1080 progressive 24/M 1080P23.98 1.485/M Gbps 422 274M/292M
1920x1080 progressive(sF) 30/M 1080PsF29.97 1.485/M Gbps 422 PR211/292M
1920x1080 progressive 30/M 1080P29.97 1.485/M Gbps 422 274M/292M
1280x720 progressive 60/M 720P59.94 1.485/M Gbps 422 296M/292M
1920x1080 interlace 50 1080i50 1.485 Gbps 422 274M/292M
1920x1080 progressive(sF) 25 1080PsF25 1.485 Gbps 422 PR211/292M
1920x1080 progressive 25 1080P25 1.485 Gbps 422 274M/292M
1920x1080 progressive(sF) 24 1080PsF24 1.485 Gbps 422 PR211/292M
1920x1080 progressive 24 1080P24 1.485 Gbps 422 274M/292M
1280x720 progressive 50 720P50 1.485 Gbps 422 296M/292M
1920x1080 progressive 60/M 1080P59.94 2.970/M Gbps 422 274M/425M
1920x1080 interlace 60/M 1080i59.94 2.970/M Gbps 444 274M/425M
1920x1080 progressive(sF) 24/M 1080PsF23.98 2.970/M Gbps 444 PR211/425M
1920x1080 progressive 24/M 1080P23.98 2.970/M Gbps 444 274M/425M
1920x1080 progressive(sF) 30/M 1080PsF29.97 2.970/M Gbps 444 PR211/425M
1920x1080 progressive 30/M 1080P29.97 2.970/M Gbps 444 274M/425M
1920x1080 progressive 50 1080P50 2.970 Gbps 422 274M/425M
1920x1080 interlace 50 1080i50 2.970 Gbps 444 274M/425M
1920x1080 progressive(sF) 25 1080PsF25 2.970 Gbps 444 PR211/425M
1920x1080 progressive 25 1080P25 2.970 Gbps 444 274M/425M
1920x1080 progressive(sF) 24 1080PsF24 2.970 Gbps 444 PR211/425M
1920x1080 progressive 24 1080P24 2.970 Gbps 444 274M/425M
Caution:
000DQG0DUH6037(VWDQGDUGV
Note:
V)VHJPHQWHG)UDPH
0,QGLFDWHV
