Ikegami CCU-430 - Page 204

186
UHK-430/CCU-430 1710 VER2 (E)
7.9 Simultaneous option
Ɣ7KHIROORZLQJ¿JXUHVKRZVWKHYLGHRRXWSXWZKHQWKH³+'6,08/´RSWLRQLVLPSOHPHQWHGLQWKH&&8
HD double speed behaviour when the SIMUL option is implemented
Selecting the double speed output or the normal speed output is possible for the SDI OUTPUT-1 and SDI OUTPUT-2 output,
DQGVHOHFWWKHQRUPDOVSHHGRXWSXWIRUWKH6',2XWSXWDQG6',2XWSXW$WWKLVWLPHWKHGRXEOHVSHHGRXWSXWLV[
3URJUHVVLYHVFDQLQ*6','8$//,1.IRUPDWDQGWKHQRUPDOVSHHGRXWSXWLV[3URJUHVVLYHVFDQLQ*6',RU
[,QWHUODFHVFDQLQ*6',RU*6',
Example of output assignment)
SDI OUTPUT-1/2 SDI OUTPUT-3/4
Image size Freq. Scan MAPPING Image size Freq. Scan MAPPING
1920x1080 119.88 Progressive EVS DL
Multicam
LSM
3G LVL-A
1920x1080 59.94
Progressive 3G LVL-A
Progressive 3G LVL-B
Interlace 3G LVL-A
Interlace 3G LVL-B
Interlace HD-SDI
1920x1080 100.00 Progressive EVS DL
Multicam
LSM
3G LVL-A
1920x1080 50.00
Progressive 3G LVL-A
Progressive 3G LVL-B
Interlace 3G LVL-A
Interlace 3G LVL-B
Interlace HD-SDI
* The compatible device with connection for the double speed output is the EVS PRODUCTION SERVER XT-3.
“EVS” and “XT-3” are registered trademarks of EVS, Belgium.
3URJUHVVLYH*/9/$%LV<&E&U,QWHUODFH*/9/$%LV5*%
