SPECIFICATIONS
9
239
UHK-430/CCU-430 1710 VER2 (E)
9.3 External Connections
■
AUDIO Connector
8VHGWRFRQQHFWIRUDXGLRRXWSXWȍEDODQFHGRXWSXW
Pin No. Name Function I/O External Interface
2
3
1
○
○
○
1
2
3
SHIELD
AUDIO (HOT)
AUDIO (COL D)
Audio line shield
AUDIO LINE HOT
AUDIO LINE COLD
GND
IN
IN
Insertion Side Insertion Side
12
3
1 2
3
CCU side : Plug receptacle HA16RD- 3P (76)
Cabl e side : XLR-3-11C (3-pin female plug) or equivalent
Camera side :
Receptacle HA16PRK-3S
Cabl e side : XLR-3-12C (3-pin male plug) or equivalent
Camera main unit has female
connector seats.
Camera mai n unit has male
connector seats.
■
OCP CSU Connector
Used to connect each type of control panel.
Pin No. Name Function I/O External Interface
Digital data output (+) from CCU to control panel
Digital data output (
- ) from CCU to control panel
Digital data output (+) from control panel to CCU
Digital data output (
- ) from control panel to CCU
DC+12V power supply to control panel
Ground for DC+12V power supply
HED(+)
HED(-)
HEC(+)
HEC(-)
+12V
+12V_RET
NC
NC
OUT
OUT
IN
IN
OUT
GND
A
B
C
D
E
F
G
H
Insertion Side
CCU side :
PRC05-RB8F1
Cable side : PRC05-PB8M or equivalent
A
G
F
H
B
C
D
E
A
B
C
F
D
ReceptacleReceptacle
○
○
○
○
○
○
○
○
