NAME and FUNCTION
2
33
UHK-430/CCU-430 1710 VER2 (E)
2.3 CCU-430
(12) SDI OUT (HD video output)- 3, 4 connector
Outputs two HD signals.
(13) SDI OUT (Main line video output)- 1, 2 connector
Outputs two 4K/HD video signals.
(14) Gigabit ETHERNET TRUNK connectors
7KHFRQQHFWRUIRU*LJDELW(WKHUQHWOLQHEHWZHHQWKHFDPHUDDQGWKH&&8
(15) HD RETURN IN (Return video input) connectors
Inputs return signals to the Camera.
,I$&7,9(7+528*+LVXVHGWKHUHWXUQYLGHRVLJQDOVDUHLQSXWWHGE\WZRV\VWHPV&+DQG&+DQGRXWSXWWHGE\WZRV\VWHPV
(CH2 and CH4).
(16) HD QTV IN connectors
Inputs the HD-SDI QTV, SMPTE 292M, video signal (for promter) to be sent to the camera.
(17) HD TRUNK OUT connector
It outputs the HD-SDI TRUNK signal from the camera.
(18) MON OUTPUT (Monitor video output) connector
Connects to the picture monitor (PM), etc.
7KH30RXWSXWVXSHULPSRVHVWKHFKDUDFWHUVRI&&80(18DQG',$*1267,&,1)250$7,217KH9)RXWSXWLVDYLGHRVHQWWR
WKHYLHZ¿QGHURIWKHFDPHUD7KH30RXWSXWDQG9)RXWSXWFDQEHDVVLJQHGWRHDFKRIOLQHV
(19) REFERENCE (Synchronization signal) connector
It inputs the V\QFKURQL]DWLRQVLJQDO+'79WULOHYHO6<1&RU6'799%6%%6
/RRSWKURXJKFRQQHFWLRQEULGJHFRQQHFWLRQLVSRVVLEOHDQGDȍWHUPLQDWRULVUHTXLUHG
(20) LAN connector (Ethernet RJ45 (8P8C)
Connects the network compatible remote controller via HUB.
(21) OCP connector
Used to connect CCU and OCP. They are connected with a CP cable.
Equivalent to CSU connector mentioned in (22), and possible to connect to CSU.
(22) CSU connector
Connects CSU with a CP cable.
Equivalent to CSU connector mentioned in (21), and possible to connect to CSU.
(23) REMOTE connector
This is a connector used to externally control the microphone volume of the camera.
(24) I/F connector
)XQFWLRQVLQFOXGLQJ'$7$7581.&DPHUD3RZHULQGLFDWRURXWSXW35(9,(:RXWSXWDUHDVVLJQHG
(25) Communication connector
,QSXWVRXWSXWV,17(5&20DQG7$//<,WDOVRLQSXWV3*0
Refrence:
Refer to Chapter 9 for terminal sequences of a connector for external connection and terminal functions.
