INSTALLATION and CONNECTION
3
45
UHK-430/CCU-430 1710 VER2 (E)
3.3 Connecting the CCU and Camera Head
■
Removing the Viewfinder
1 Check the power of the camera is turned off.
2 Remove the VF connector.
3 Loosen the VF fixing knob.
4 Slide the VF retaining guide lever and release the lock of the lock pin. Then, slide the viewfinder to remove it.
Turn the eyepiece 90 degrees and stand it up when removing the viewfinder, so that you can remove it easily.
To Next Page
