Intel 386

To Next Page

To Previous Page

6-39

BUS INTERFACE UNIT

6.6.1.1 System Configuration

The Intel387 SX Math Coprocessor can be interfaced to the Intel386 EX embedded processor as

shown in Figure 6-15.

Figure 6-15. Intel386 EX Processor to Intel387 SX Math Coprocessor Interface

A dedicated communication protocol makes possible high-speed transfer of opcodes and oper-

ands between the Intel386 EX processor and the Intel387 SX math coprocessor. Most control pins

of the Intel387 SX Math Coprocessor are connected directly to Intel386 EX processor pins.

BUSY#

PEREQ

ERROR#

READY#

BUSY#

PEREQ

ERROR#

READY#

Clock

Generator

CPUCLK2

CLK2

A2852-02

Synchronous

Reset

LBA#

D15:0

W/R#

ADS#

NPS1#

NPS2

CMD0#

W/R#

ADS#

M/IO#

A23

READYO#

NUMCLK2

STEN

CKM

D15:0

80386EX

80387SX

RESETIN

RESET

Intel386™ EX

Embedded Processor

Intel387™ SX

Math Coprocessor
