Intel386™ EX EMBEDDED MICROPROCESSOR USER’S MANUAL
D-52
D.50 RBR n
Receive Buffer
RBR0, RBR1
(read only)
Expanded Addr:
ISA Addr:
Reset State:
RBR0 RBR1
F4F8H F8F8H
03F8H 02F8H
XXH XXH
7 0
RB7 RB6 RB5 RB4 RB3 RB2 RB1 RB0
Bit
Number
Bit
Mnemonic
Function
7–0 RB7:0 Receive Buffer Bits:
These bits make up the last word received. The receiver shifts bits in,
starting with the least-significant-bit. The receiver then strips off the
asynchronous bits (start, parity, and stop) and transfers the received
data bits from the receive shift register to the receive buffer.
NOTE: The receive buffer register shares an address port with other SIO registers. Bit 7 (DLAB) of
the LCR
n must be cleared in order to read the receive buffer register.
