Intel386™ EX EMBEDDED MICROPROCESSOR USER’S MANUAL
15-10
15.4.4 Refresh Address Register (RFSADD)
RFSADD contains the bits A13:1 of the refresh address. The lowest address bit is not used be-
cause most DRAM devices contain word-wide memory arrays; for all refresh operations, the low-
est address bit remains set.
Figure 15-5. Refresh Address Register (RFSADD)
Refresh Address
RFSADD
(read/write)
Expanded Addr:
ISA Addr:
Reset State:
F4A6H
—
00FFH
15 8
— — RA13 RA12 RA11 RA10 RA9 RA8
7 0
RA7 RA6 RA5 RA4 RA3 RA2 RA1 1
Bit
Number
Bit
Mnemonic
Function
15–14 — Reserved. These bits are undefined; for compatibility with future devices,
do not modify these bits.
13–1 RA13:1 Refresh Address Bits:
These bits comprise A13:1 of the refresh address.
0 — Refresh Bit 0:
A0 of the refresh address. This bit is always 1 and is read-only.

Intel 386 Specifications

General

Architecture	x86
Clock Speed	12 MHz to 40 MHz
Transistor Count	275, 000
Data Bus Width	32-bit
Address Bus Width	32-bit
Instruction Set	x86
Introduced	1985
Maximum Memory	4 GB
Operating Modes	Real mode, Protected mode, Virtual 8086 mode
MMU	Yes
Voltage	5V
Model	Intel 386
Package	PGA
Process	1.5 μm to 1 μm
