Intel386™ EX EMBEDDED MICROPROCESSOR USER’S MANUAL

5-8

Table 5-1. Master’s IR3 Connections

Function INTCFG.6 MCR1.3 P3CFG.1

IR3 connected to SIOINT1

P3.1 selected at pin (P3.1)

0X0

IR3 connected to SIOINT1

OUT1 connected to pin (TMROUT1)

0X1

IR3 internally driven low

P3.1 selected at pin (P3.1)

100

IR3 connected to pin (INT8) 1 0 1

IR3 connected to SIOINT1

P3.1 selected at pin (P3.1)

110

IR3 connected to SIOINT1

pin (INT8) must not be left floating

111

NOTE: X is a don’t care

Table 5-2. Master’s IR4 Connections

Function INTCFG.5 MCR0.3 P3CFG.0

IR4 connected to SIOINT0

P3.0 selected at pin (P3.0)

0X0

IR4 connected to SIOINT0

OUT0 connected to pin (TMROUT0)

0X1

IR4 internally driven low

P3.0 selected at pin (P3.0)

100

IR4 connected to pin (INT9) 1 0 1

IR4 connected to SIOINT0

P3.0 selected at pin (P3.0)

110

IR4 connected to SIOINT0

pin (INT9) must not be left floating

111

NOTE: X is a don’t care
