Intel 386 User Manual

D-11
SYSTEM REGISTER QUICK REFERENCE
D.6 CS n MSKL (UCSMSKL)
Chip-select Low Mask
CS
n MSKL ( n = 0–6), UCSMSKL
(read/write)
Expanded Addr:
ISA Addr:
Reset State:
F404H, F40CH
F414H, F41CH
F424H, F42CH
F434H, F43CH
—
0000H (CS
n MSKL)
FFFFH (UCSMSKL)
15 8
CM5 CM4 CM3 CM2 CM1 CMSMM — —
7 0
———— ———CSEN
Bit
Number
Bit
Mnemonic
Function
15–11 CM5:1 Chip-select Mask Value Lower Bits:
Defines the lower 5 bits of the channel’s 15-bit mask. The mask bits
CM5:1 and the address bits CA5:1 form a masked address that is
compared to memory address bits A15:11 or I/O address bits A5:1.
10 CMSMM SMM Mask Bit:
0 = The SMM address bit is not masked.
1 = Masks the SMM address bit in the channel’s Chip-Select Low
Address register. When the SMM address bit is masked, an address
match activates the chip-select, regardless of whether the processor
is in SMM.
9–1 — Reserved; for compatibility with future devices, write zeros to these bits.
0 CSEN Chip-select Enable:
0 = Disables the chip-select channel.
1 = Enables the chip-select channel.
