D-31

SYSTEM REGISTER QUICK REFERENCE

D.28 IDCODE

Identification Code Register

IDCODE Reset State:

2027 0013H (3V)

2827 0013H (5V)

31 24

00100 (3V)

1 (5V)

000

23 16

0010 0111

15 8

0000 0000

7 0

0001 0011

Bit

Number

Bit

Mnemonic

Function

31–28

V3:0

Device version number.

27–12 PN15:0 Device part number.

11–1 MFR10:0 Manufacturer identification (compressed JEDEC106-A code).

0 IDP Identification Present. Always true for this device.

This is the first data bit shifted out of the device during a data scan

immediately following an exit from the test-logic-reset state. A one

indicates that an IDCODE register is present. (A zero originates from the

BYPASS register and indicates that the device being interrogated has no

IDCODE register.)
