Intel 386

Intel386™ EX EMBEDDED MICROPROCESSOR USER’S MANUAL
12-30
DMACHR
(write only)
F019H — DMA Chaining:
Enables chaining buffer-transfer mode for a specified
channel.
DMAIEN
(read/write)
F01CH — DMA Interrupt Enable:
Connects the channel transfer complete status
signals to the interrupt request output (DMAINT).
DMAIS
(read only)
F019H — DMA Interrupt Status:
Indicates which signal generated an interrupt request:
channel 0 transfer complete, channel 1 transfer
complete, channel 0 chaining, or channel 1 chaining
status.
DMAOVFE
(read/write)
F01DH — DMA Overflow Enable:
Included for 8237A compatibility. Controls whether all
26 bits or only the lower 16 bits of the requester and
target addresses are incremented or decremented
during buffer transfers. Controls whether the byte
count is 24 bits or 16 bits.
Table 12-3. DMA Registers (Sheet 3 of 3)
Register
Expanded
Address
PC/AT*
Address
Description
