855GME Chipset and Intel
®
6300ESB ICH Embedded Platform Design Guide
System Memory Design Guidelines (DDR-SDRAM)
Table 34. DDR SDQ/SDM/SDQS Package Lengths (Sheet 1 of 2)
Signal Pin Number
Pkg Length
(mils)
Signal Pin Number
Pkg Length
(mils)
SDQ[0] AF2 785 SDQ[32] AH16 766
SDQ[1] AE3 751 SDQ[33] AG17 558
SDQ[2] AF4 690 SDQ[34] AF19 510
SDQ[3] AH2 903 SDQ[35] AE20 579
SDQ[4] AD3 682 SDQ[36] AD18 408
SDQ[5] AE2 739 SDQ[37] AE18 458
SDQ[6] AG4 741 SDQ[38] AH18 658
SDQ[7] AH3 845 SDQ[39] AG19 596
SDQ[8] AD6 607 SDQ[40] AH20 677
SDQ[9] AG5 756 SDQ[41] AG20 730
SDQ[10] AG7 685 SDQ[42] AF22 562
SDQ[11] AE8 558 SDQ[43] AH22 702
SDQ[12] AF5 734 SDQ[44] AF20 563
SDQ[13] AH4 825 SDQ[45] AH19 644
SDQ[14] AF7 644 SDQ[46] AH21 716
SDQ[15] AH6 912 SDQ[47] AG22 783
SDQ[16] AF8 622 SDQ[48] AE23 592
SDQ[17] AG8 624 SDQ[49] AH23 752
SDQ[18] AH9 676 SDQ[50] AE24 666
SDQ[19] AG10 634 SDQ[51] AH25 817
SDQ[20] AH7 710 SDQ[52] AG23 639
SDQ[21] AD9 508 SDQ[53] AF23 667
SDQ[22] AF10 569 SDQ[54] AF25 707
SDQ[23] AE11 469 SDQ[55] AG25 783
SDQ[24] AH10 648 SDQ[56] AH26 834
SDQ[25] AH11 622 SDQ[57] AE26 701
SDQ[26] AG13 572 SDQ[58] AG28 808
SDQ[27] AF14 655 SDQ[59] AF28 756
SDQ[28] AG11 599 SDQ[60] AG26 782
SDQ[29] AD12 460 SDQ[61] AF26 748
SDQ[30] AF13 536 SDQ[62] AE27 673
SDQ[31] AH13 642 SDQ[63] AD27 608
SDQ[64] AG14 566
SDQ[65] AE14 477
SDQ[66] AE17 571
