Page #295 background image
January 2007 295
Intel
®
855GME Chipset and Intel
®
6300ESB ICH Embedded Platform Design Guide
Schematic Checklist Summary
12.4.14 Serial ATA Checklist
12.4.15 IDE Checklist
SPKR See Section 9.4.3 for more information.
Strap function: No Reboot (See the
6300ESB EDS for more information)
Has integrated pull-down. The integrated
pull-down is only enabled at boot/reset for
strapping functions; at all other times, the
pull-down is disabled.
Table 145. Serial ATA Checklist
Checklist Items Recommendations Interface Not Used Reason/Impact
SATA[0:1]RXN,
SATA[0:1]RXP
No extra series termination
resistors or other pull-ups/pull-
downs are required.
May leave as no
connect
SATA[0:1]TXN,
SATA[0:1]TXP
No extra series termination
resistors or other pull-ups/pull-
downs are required.
May leave as no
connect
SATACLKN
Connect a 33
Ω series resistor
between the CK409 and this signal
May leave as no
connect
SATACLKP
Connect a 33
Ω series resistor
between the CK409 this signal
May leave as no
connect
SATALED#
Recommend a weak external pull-
up to Vcc3.3
May leave as no
connect
Open Drain signal
SATARBIASN
Short this signal with SATARBIASP
at package. Connect to a 24.9
Ω
±1% resister to GND.
May leave as no
connect
SATARBIASP
Short this signal with SATARBIASN
at package. This signal can be
connected to the same 24.9
Ω ±1%
resistor only if SATARBIASP is not
used to connect the resistor to
ground.
May leave as no
connect
See section
Section 9.1.1.5
Table 146. IDE Checklist (Sheet 1 of 2)
Checklist Items Recommendations Interface Not Used Reason/Impact
PDD[15:0],
SDD[15:0]
No extra series termination
resistors or other pull-ups/pull-
downs are required.
PDD7/SDD7 does not require a
10 K
Ω pull-down resistor.
Refer to
ATA ATAPI-6 specification.
May leave as no
connect
These signals have
integrated series resistors.
NOTE: Simulation data
indicates that the
integrated series
termination
resistors are a
nominal 33
Ω but
may range from
21
Ω to 75 Ω.
Table 144. Miscellaneous Signals Checklist
Checklist Items Recommendations Reason/Impact
