Intel SC5650BCDP Technical Product Specification

Intel
®
Server Board S5500BC TPS Appendix B: Sensor Tables
Revision 1.8 Intel order number: E42249-009 129
Full Sensor Name
(Sensor name in SDR)
Sensor #
Platform
Applicability
Sensor Type
Event /
Reading Type
Event Offset
Triggers
Contrib. To
System Status
Assert
/ De-
assert
Readabl
e
Value /
Offsets
Event
Data
Rearm
Stand-
by
BB +5.0V
(BB +5.0V)
19h
All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As
and
De
Analog
R, T
A
–
BB +5.0V STBY
(BB +5.0V STBY)
1Ah
All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As
and
De
Analog
R, T
A
X
BB +12.0V
(BB +12.0V)
1Bh
All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As
and
De
Analog
R, T
A
–
BB -12.0V
(BB -12.0V)
1Ch
All
Voltage
02h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As
and
De
Analog
R, T
A
–
Baseboard Temperature
(Baseboard Temp)
20h
All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As
and
De
Analog
R, T
A
X
Front Panel Temperature
(Front Panel Temp)
21h
All
Temperature
01h
Threshold
01h
[u,l] [c,nc]
nc = Degraded
c = Non-fatal
As
and
De
Analog
R, T
A
X
IOH Thermal Margin
(IOH Therm Margin)
22h
All
Temperature
01h
Threshold
01h
[u] [c,nc]
nc = Degraded
c = Non-fatal
As
and
De
Analog
R, T
A
–
Processor 1 Memory
Thermal Margin
(Mem P1 Thrm Mrgn)
23h
All
Temperature
01h
Threshold
01h
[u] [c,nc]
nc = Degraded
c = Non-fatal
As
and
De
Analog
R, T
A
–
Processor 2 Memory
Thermal Margin
(Mem P2 Thrm Mrgn)
24h
Dual
processor
only
Temperature
01h
Threshold
01h
[u] [c,nc]
nc = Degraded
c = Non-fatal
As
and
De
Analog
R, T
A
–
Fan Tachometer Sensors
(Chassis specific
sensor names)
30h–39h
Chassis-
specific
Fan
04h
Threshold
01h
[l] [c,nc]
nc = Degraded
c = Non-fatal
2
As
and
De
Analog
R, T
M
–
